LED Load Simulator Model 63110A/ 63113A/63115A

LED Load Simulator Model 63110A/ 63113A/63115A

LED Load Simulator Model 63110A/ 63113A/63115A

Key Features

  • Unique LED mode for LED power driver test
  • Programmable LED dynamic resistance (Rd)
  • Programmable internal resistance (Rr) for simulating LED ripple current
  • Fast response for PWM dimming test
  • Up to eight channels in one mainframe
  • 16-bit precision voltage and current measurement with dual-range
  • Full Protection: OC, OP, OT protection and OV alarm

As a constant current source, the LED driver has an output voltage range with a constant output current. LED drivers are usually tested in one of the following ways:

  • With LEDs
  • Using resistors for loading

Using Electronic Loads in Constant Resistance (CR) mode, or Constant Voltage (CV) mode
